MAL-SG Line

€ 99.00

Quantity:

Perfectly Conditioned. For Strain Gauge.

Load and pressure signals of strain gauges and sensors based on strain gauge technology can optimally be adjusted to the input of a PC data acquisition system with the miniature measuring amplifiers MAL-SG2 and MAL-SG5. The measuring amplifiers feature 5V sensor supply for connected sensors.

Minimum Size. Great Performance. Small Price.

The miniature format of the MAL-SG2/MAL-SG5 is ideal to realize measurement applications even if the installation is in problematic locations. Despite the small size, the measuring amplifier features great functionality. All this at a reasonable price.

Connect Strain Gauge. ±2mV/V or ±5mV/V. Get ±5V.

The two measuring amplifier types differ in sensitivity of ±2mV/V (MAL-SG2) or ±5mV/V (MAL-SG5). A ±5V signal proportional to the input signal is provided at the output. The MAL-SG5 with less sensitivity is recommended for external supply more than +5V or high offset errors.

Compatibility.

The MAL series provides a great variety of measuring amplifiers, measuring converters, or filter modules. They can be used in any combination allowing for the solution of the most individual measuring tasks.

Get Connected.

With the backplanes of the BP series varying in size and design, signal connection is easy. The modules just have to be plugged on the relevant slot of the backplane.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF).

size: 24-pin DIL IC
50Hz bandwidth
differential input
MAL-SG2: sensitivity 2mV/V
MAL-SG5: sensitivity 5mV/V
sensor supply 5V
output filter 6dB/oct.

MAL-SG Series

Datenblatt - Miniature measuring amplifier MAL-SG2/5 for strain gauge (v. 6.0.1)
